Thread: Corsair 800D, Watercooled log

  1. #1
    I R Toff Pandi! TAKTAK's Avatar
    Join Date
    Mar 2008
    Location
    Vergon6
    Posts
    7,410
    Thanks
    525
    Thanked
    995 times in 735 posts
    • TAKTAK's system
      • Motherboard:
      • MSI P55 GD65
      • CPU:
      • i7 860 @ 3.62GHz under an XSPC RASA
      • Memory:
      • 8GB 2133MHZ Corsair Vengeance
      • Storage:
      • 80GB Intel G2 SSD + 500GB + 640GB + 250GB WD AAKs + 2x1TB Samsung (1 Dead) + 500GB Maxtor
      • Graphics card(s):
      • EVGA SSC GTX260 216 55nm under an EK FC260 GTX
      • PSU:
      • Corsair HX620w
      • Case:
      • Corsair 800D, PA120.3 in the roof with 6 NF-P12s in Push-Pull
      • Operating System:
      • 7 x64
      • Monitor(s):
      • 24" Yuraku YV24WBH1 - SA-LTM240M2-L01 Panel & 32" LCD HDTV (1080i) Digihome tesco special :D
      • Internet:
      • 76Mb Fibre

    Corsair 800D, Watercooled log

    Index:

    1. GPU Block, tubing, general = this post
    2. 800D arrives, unboxing, more 800D, yet more 800D
    3. Size comparison between Lian Li A05, CM690, 800D
    4. Aircooled build transfer and temperature readings
    5. WC gear arrives
    6. CPU block and GPU block install, in case
    7. Tapping the radiator to M4
    8. Most of the loop done (Waiting for compression collar)
    9. Drive bay stealthing


    /index






    I finally decided to leap into watercooling proper, my current rig is as follows:

    i7 860 under an NH-U12P SE2
    MSI P55 GD65
    4GB 2000mhz GSkill RipJaw
    80GB Intel G2 SSD
    500GB WD AAKS
    640GB WD AAKS
    250GB WD AAKs
    250GB WD AAKs
    EVGA SSC GTX260 216 55nm
    Corsair HX620w
    CM 690

    And being recycled are:

    i7 860
    MSI P55 GD65
    4GB 2000mhz GSkill RipJaw
    80GB Intel G2 SSD
    500GB WD AAKS
    640GB WD AAKS
    250GB WD AAKs
    250GB WD AAKs
    EVGA SSC GTX260 216 55nm
    Corsair HX620w
    Noctua's (need a colour change though....)

    In addition to:

    EK FC260 GTX
    XSPC Rasa
    PA120.3 (15mm)
    Laing DDC Ultra 18w
    XSPC dual bay res (single DDC)
    Corsair 800D
    Fittings
    1/2 ID 3/4 OD tubing, blue


    Now the first thing that is going to annoy me is the PSU... It has a red label on it... everything else is blue/black so i'll have to fix that...

    So first actual thing to note is that everything is still in the post, well... Almost everything...

    I have my GFX block, EK FC-260GTX with the Acetal top (black to match the rest of the build):





    The barbs will be gone in favour of black compression fittings

    Nice and flat (and shiny):



    So the second thing i already have gathering dust is the tubing:

    This picture doesn't really show the colour well:



    This one shows it better:




    No dye going near my loop... (Well apart from Vinyl dye to *fix* the Noctuas)

    The 800D is on it's way (Dabs, surprisingly) so should be here between now and Fri, and Specialtech's (again, surprisingly) load shouldn't take too long hopefully

    It's go time!
    Last edited by TAKTAK; 16-05-2010 at 10:03 AM.
    Post Counts and Other Rewards, Rules, Folding@Home, Fans: Push vs Pull vs Push-Pull, Corsair PSU OEMs.

    Quote Originally Posted by razer121 View Post
    Would you like me to enter you? it would be my pleasure
    TAKTAK.co.uk

  2. #2
    Senior Member Hicks12's Avatar
    Join Date
    Jan 2008
    Location
    Plymouth-SouthWest
    Posts
    6,554
    Thanks
    1,066
    Thanked
    331 times in 287 posts
    • Hicks12's system
      • Motherboard:
      • Asus P8Z68-V
      • CPU:
      • Intel i5 2500k@4ghz, cooled by EK Supreme HF
      • Memory:
      • 8GB Kingston hyperX ddr3 PC3-12800 1600mhz
      • Storage:
      • 64GB M4/128GB M4 / WD 640GB AAKS / 1TB Samsung F3
      • Graphics card(s):
      • Palit GTX460 @ 900Mhz Core
      • PSU:
      • 675W ThermalTake ThoughPower XT
      • Case:
      • Lian Li PC-A70 with modded top for 360mm rad
      • Operating System:
      • Windows 7 Professional 64bit
      • Monitor(s):
      • Dell U2311H IPS
      • Internet:
      • 10mb/s cable from virgin media

    Re: Corsair 800D, Watercooled log

    Taktak, care to tell me how much you spent (roughly) on the watercooling parts? Ive a basic WC setup now but after i recieve my grant I will be using it to fund a new gpu and other components, one possible upgrade would be the WC setup so im interested .
    Quote Originally Posted by snootyjim View Post
    Trust me, go into any local club and shout "I've got dual Nehalem Xeons" and all of the girls will practically collapse on the spot at the thought of your e-penis

  3. #3
    I R Toff Pandi! TAKTAK's Avatar
    Join Date
    Mar 2008
    Location
    Vergon6
    Posts
    7,410
    Thanks
    525
    Thanked
    995 times in 735 posts
    • TAKTAK's system
      • Motherboard:
      • MSI P55 GD65
      • CPU:
      • i7 860 @ 3.62GHz under an XSPC RASA
      • Memory:
      • 8GB 2133MHZ Corsair Vengeance
      • Storage:
      • 80GB Intel G2 SSD + 500GB + 640GB + 250GB WD AAKs + 2x1TB Samsung (1 Dead) + 500GB Maxtor
      • Graphics card(s):
      • EVGA SSC GTX260 216 55nm under an EK FC260 GTX
      • PSU:
      • Corsair HX620w
      • Case:
      • Corsair 800D, PA120.3 in the roof with 6 NF-P12s in Push-Pull
      • Operating System:
      • 7 x64
      • Monitor(s):
      • 24" Yuraku YV24WBH1 - SA-LTM240M2-L01 Panel & 32" LCD HDTV (1080i) Digihome tesco special :D
      • Internet:
      • 76Mb Fibre

    Re: Corsair 800D, Watercooled log

    My bill with SpecialTech (would have put it Toms way but there were a few things out of stock , same with watercoolingUk, and watercooledpcs was dead) is:

    £ 252.57, for (copy/paste ):

    Thermochill PA120.3 360 Radiator with 15mm Fan Spacing #9300

    XSPC Rasa CPU Waterblock for Intel 775, 1366, 1156 : RASA #11537

    Laing DDC-1+ Ultra Pump 600 L/hr 18W (MCP355) : DDC-1+ T #3179

    XSPC 5.25" Dual Drive Bay Reservoir for One Laing DDC Pump Multi Fascia : DDCBAYONE #9974

    3/8" Thread Compression Fitting for 1/2" ID - 3/4" OD Tubing : Black Nickel #11208

    1/4" Thread 45° Rotary Compression Fitting for 1/2" ID - 3/4" OD (13-19mm) Tubing : Black #11394

    1/4" Thread Compression Fitting for 1/2" ID - 3/4" OD Tubing : Black Nickel #11206

    PT PHN Nuke Concentrated Biocide 10ml #9643

    Silver Anti Algae KillCoil by iandh #11143

    Plastic Funnel - Ideal for Watercooling #1957

    Because i allready have my GPU block, TIM, distilled water and tubing so add an extra round figure of £50 on to cover all the extras, so ~£300 ()
    Post Counts and Other Rewards, Rules, Folding@Home, Fans: Push vs Pull vs Push-Pull, Corsair PSU OEMs.

    Quote Originally Posted by razer121 View Post
    Would you like me to enter you? it would be my pleasure
    TAKTAK.co.uk

  4. Received thanks from:

    Hicks12 (11-05-2010)

  5. #4
    Not a good person scaryjim's Avatar
    Join Date
    Jan 2009
    Location
    Manchester
    Posts
    15,029
    Thanks
    1,193
    Thanked
    2,242 times in 1,844 posts
    • scaryjim's system
      • Motherboard:
      • Dell Inspiron
      • CPU:
      • Core i5 8250U
      • Memory:
      • 1x 8GB DDR4 2400
      • Storage:
      • 128GB M.2 SSD + 1TB HDD
      • Graphics card(s):
      • Radeon R5 230
      • PSU:
      • Battery/Dell brick
      • Case:
      • Dell Inspiron 5570
      • Operating System:
      • Windows 10
      • Monitor(s):
      • 15" 1080p laptop panel

    Re: Corsair 800D, Watercooled log

    Quote Originally Posted by TAKTAK View Post
    ... would have put it Toms way but ...
    Who that? I'll be doing my first water cooling set up this summer, so could do with knowing where's best to buy my bits from (as it were )

  6. #5
    I R Toff Pandi! TAKTAK's Avatar
    Join Date
    Mar 2008
    Location
    Vergon6
    Posts
    7,410
    Thanks
    525
    Thanked
    995 times in 735 posts
    • TAKTAK's system
      • Motherboard:
      • MSI P55 GD65
      • CPU:
      • i7 860 @ 3.62GHz under an XSPC RASA
      • Memory:
      • 8GB 2133MHZ Corsair Vengeance
      • Storage:
      • 80GB Intel G2 SSD + 500GB + 640GB + 250GB WD AAKs + 2x1TB Samsung (1 Dead) + 500GB Maxtor
      • Graphics card(s):
      • EVGA SSC GTX260 216 55nm under an EK FC260 GTX
      • PSU:
      • Corsair HX620w
      • Case:
      • Corsair 800D, PA120.3 in the roof with 6 NF-P12s in Push-Pull
      • Operating System:
      • 7 x64
      • Monitor(s):
      • 24" Yuraku YV24WBH1 - SA-LTM240M2-L01 Panel & 32" LCD HDTV (1080i) Digihome tesco special :D
      • Internet:
      • 76Mb Fibre

    Re: Corsair 800D, Watercooled log

    Quote Originally Posted by scaryjim View Post
    Who that? I'll be doing my first water cooling set up this summer, so could do with knowing where's best to buy my bits from (as it were )
    Tom at ChilledPC, top, top bloke http://forums.hexus.net/members/welshtom.html
    Post Counts and Other Rewards, Rules, Folding@Home, Fans: Push vs Pull vs Push-Pull, Corsair PSU OEMs.

    Quote Originally Posted by razer121 View Post
    Would you like me to enter you? it would be my pleasure
    TAKTAK.co.uk

  7. Received thanks from:

    scaryjim (12-05-2010)

  8. #6
    Senior Member Hicks12's Avatar
    Join Date
    Jan 2008
    Location
    Plymouth-SouthWest
    Posts
    6,554
    Thanks
    1,066
    Thanked
    331 times in 287 posts
    • Hicks12's system
      • Motherboard:
      • Asus P8Z68-V
      • CPU:
      • Intel i5 2500k@4ghz, cooled by EK Supreme HF
      • Memory:
      • 8GB Kingston hyperX ddr3 PC3-12800 1600mhz
      • Storage:
      • 64GB M4/128GB M4 / WD 640GB AAKS / 1TB Samsung F3
      • Graphics card(s):
      • Palit GTX460 @ 900Mhz Core
      • PSU:
      • 675W ThermalTake ThoughPower XT
      • Case:
      • Lian Li PC-A70 with modded top for 360mm rad
      • Operating System:
      • Windows 7 Professional 64bit
      • Monitor(s):
      • Dell U2311H IPS
      • Internet:
      • 10mb/s cable from virgin media

    Re: Corsair 800D, Watercooled log

    Holy crap thats alot of cash .

    Is the Thermochill PA120.3 really that good? Cause £70 for a brand new one is a lot, i know thermochill have a good rep so i assume this beats almost everything? Are the XSPC ones (that £40) acceptable?.

    Make sure you do a full system temp test, because if its good then I will have to keep an eye out for second hand parts of these floating on ebay .
    Quote Originally Posted by snootyjim View Post
    Trust me, go into any local club and shout "I've got dual Nehalem Xeons" and all of the girls will practically collapse on the spot at the thought of your e-penis

  9. #7
    I R Toff Pandi! TAKTAK's Avatar
    Join Date
    Mar 2008
    Location
    Vergon6
    Posts
    7,410
    Thanks
    525
    Thanked
    995 times in 735 posts
    • TAKTAK's system
      • Motherboard:
      • MSI P55 GD65
      • CPU:
      • i7 860 @ 3.62GHz under an XSPC RASA
      • Memory:
      • 8GB 2133MHZ Corsair Vengeance
      • Storage:
      • 80GB Intel G2 SSD + 500GB + 640GB + 250GB WD AAKs + 2x1TB Samsung (1 Dead) + 500GB Maxtor
      • Graphics card(s):
      • EVGA SSC GTX260 216 55nm under an EK FC260 GTX
      • PSU:
      • Corsair HX620w
      • Case:
      • Corsair 800D, PA120.3 in the roof with 6 NF-P12s in Push-Pull
      • Operating System:
      • 7 x64
      • Monitor(s):
      • 24" Yuraku YV24WBH1 - SA-LTM240M2-L01 Panel & 32" LCD HDTV (1080i) Digihome tesco special :D
      • Internet:
      • 76Mb Fibre

    Re: Corsair 800D, Watercooled log

    Quote Originally Posted by Hicks12 View Post
    Holy crap thats alot of cash .

    Is the Thermochill PA120.3 really that good? Cause £70 for a brand new one is a lot, i know thermochill have a good rep so i assume this beats almost everything? Are the XSPC ones (that £40) acceptable?.

    Make sure you do a full system temp test, because if its good then I will have to keep an eye out for second hand parts of these floating on ebay .
    The Thermochill excels in terms of low restriction, and has overall performance in terms of robustness with fans used, in that low static pressure will still reap decent results, but as Fraz rightly says, the XSPC RX360 pulls slightly ahead while using lower static pressure, i'm not 100% sure but i think the RX is more restrictive too

    The RS and the Lite are ~ half the width of the PA120.3 and RX, so if you're strapped for space then they are a good option, however your best performance will come from the RX's or PA120.3, and don't even bother with feser

    It's not so much as the Thermochill beats everything (it is right near the top though) but it is very well rounded , plus it's English , Steve Verity used to own them until not too long ago, yet another top bloke

    And yep, temps will be on the cards, obviously not very scientific as i'll be moving cases at the same time as well and i won't have another rad to compare with.

    The main cost is the Rad, CPU block and Pump (well, that's basically all of the loop ) and that is where your performance is, if you skimp you will lose some potential cooling (it may well not be that much, but it's still a loss )


    I want my deliveries
    Post Counts and Other Rewards, Rules, Folding@Home, Fans: Push vs Pull vs Push-Pull, Corsair PSU OEMs.

    Quote Originally Posted by razer121 View Post
    Would you like me to enter you? it would be my pleasure
    TAKTAK.co.uk

  10. #8
    Senior Member Hicks12's Avatar
    Join Date
    Jan 2008
    Location
    Plymouth-SouthWest
    Posts
    6,554
    Thanks
    1,066
    Thanked
    331 times in 287 posts
    • Hicks12's system
      • Motherboard:
      • Asus P8Z68-V
      • CPU:
      • Intel i5 2500k@4ghz, cooled by EK Supreme HF
      • Memory:
      • 8GB Kingston hyperX ddr3 PC3-12800 1600mhz
      • Storage:
      • 64GB M4/128GB M4 / WD 640GB AAKS / 1TB Samsung F3
      • Graphics card(s):
      • Palit GTX460 @ 900Mhz Core
      • PSU:
      • 675W ThermalTake ThoughPower XT
      • Case:
      • Lian Li PC-A70 with modded top for 360mm rad
      • Operating System:
      • Windows 7 Professional 64bit
      • Monitor(s):
      • Dell U2311H IPS
      • Internet:
      • 10mb/s cable from virgin media

    Re: Corsair 800D, Watercooled log

    I want my grant and to be given my second job now.... then id be able to afford this setup xD. If i manage to land this second job ill have about 1.5 grand after my birthday in july and so will blow it on this and all the new stuff.

    Need to find a suitable case, how much was the 800D? £150? Let me know what you think of it because if the above does happen i may well go all the way and replace this case i modded because a quad rad wont fit xD.
    Quote Originally Posted by snootyjim View Post
    Trust me, go into any local club and shout "I've got dual Nehalem Xeons" and all of the girls will practically collapse on the spot at the thought of your e-penis

  11. #9
    I R Toff Pandi! TAKTAK's Avatar
    Join Date
    Mar 2008
    Location
    Vergon6
    Posts
    7,410
    Thanks
    525
    Thanked
    995 times in 735 posts
    • TAKTAK's system
      • Motherboard:
      • MSI P55 GD65
      • CPU:
      • i7 860 @ 3.62GHz under an XSPC RASA
      • Memory:
      • 8GB 2133MHZ Corsair Vengeance
      • Storage:
      • 80GB Intel G2 SSD + 500GB + 640GB + 250GB WD AAKs + 2x1TB Samsung (1 Dead) + 500GB Maxtor
      • Graphics card(s):
      • EVGA SSC GTX260 216 55nm under an EK FC260 GTX
      • PSU:
      • Corsair HX620w
      • Case:
      • Corsair 800D, PA120.3 in the roof with 6 NF-P12s in Push-Pull
      • Operating System:
      • 7 x64
      • Monitor(s):
      • 24" Yuraku YV24WBH1 - SA-LTM240M2-L01 Panel & 32" LCD HDTV (1080i) Digihome tesco special :D
      • Internet:
      • 76Mb Fibre

    Re: Corsair 800D, Watercooled log

    Quote Originally Posted by Hicks12 View Post
    I want my grant and to be given my second job now.... then id be able to afford this setup xD. If i manage to land this second job ill have about 1.5 grand after my birthday in july and so will blow it on this and all the new stuff.

    Need to find a suitable case, how much was the 800D? £150? Let me know what you think of it because if the above does happen i may well go all the way and replace this case i modded because a quad rad wont fit xD.
    Higher

    £210

    I wanted the TYR X2000F, but knowing Lian Li, it'll be ~£380
    Post Counts and Other Rewards, Rules, Folding@Home, Fans: Push vs Pull vs Push-Pull, Corsair PSU OEMs.

    Quote Originally Posted by razer121 View Post
    Would you like me to enter you? it would be my pleasure
    TAKTAK.co.uk

  12. #10
    Senior Member Hicks12's Avatar
    Join Date
    Jan 2008
    Location
    Plymouth-SouthWest
    Posts
    6,554
    Thanks
    1,066
    Thanked
    331 times in 287 posts
    • Hicks12's system
      • Motherboard:
      • Asus P8Z68-V
      • CPU:
      • Intel i5 2500k@4ghz, cooled by EK Supreme HF
      • Memory:
      • 8GB Kingston hyperX ddr3 PC3-12800 1600mhz
      • Storage:
      • 64GB M4/128GB M4 / WD 640GB AAKS / 1TB Samsung F3
      • Graphics card(s):
      • Palit GTX460 @ 900Mhz Core
      • PSU:
      • 675W ThermalTake ThoughPower XT
      • Case:
      • Lian Li PC-A70 with modded top for 360mm rad
      • Operating System:
      • Windows 7 Professional 64bit
      • Monitor(s):
      • Dell U2311H IPS
      • Internet:
      • 10mb/s cable from virgin media

    Re: Corsair 800D, Watercooled log

    Ouch, it does look like the best case though and since cases last years I feel its worth the investment. I have a case thats like 10 years old and is being used to this date (after just over a year with a cm690 xD).

    Yeh the TYR X2000F will be expensive and looks the part, typical Lian li .

    A case that i was really hoping to get as the corsair one is a bit to much for me was the silverstone black raven, but i found out that its a crap case for WC... too small although i love the concept .
    Quote Originally Posted by snootyjim View Post
    Trust me, go into any local club and shout "I've got dual Nehalem Xeons" and all of the girls will practically collapse on the spot at the thought of your e-penis

  13. #11
    DILLIGAF GoNz0's Avatar
    Join Date
    Jun 2006
    Location
    Derby
    Posts
    10,864
    Thanks
    632
    Thanked
    1,190 times in 943 posts
    • GoNz0's system
      • Motherboard:
      • Asus Rampage V Extreme
      • CPU:
      • i7 something X99 based
      • Memory:
      • 16gb GSkill
      • Storage:
      • 4 SSD's + WD Red
      • Graphics card(s):
      • GTX980 Strix WC
      • PSU:
      • Enermax Galaxy 1250 (9 years and counting)
      • Case:
      • Corsair 900D
      • Operating System:
      • win10 64bit
      • Monitor(s):
      • Dell 24"
      • Internet:
      • 220mb Cable

    Re: Corsair 800D, Watercooled log

    well im now thinking of asking tom to make me a 140mm rad bracket like his 120mm version and hanging a 140.3 off the back of the case.. why you ask, well 2 of these to match the rest of the koolance kit in my rig

    http://www.chilledpc.co.uk/shop/prod...oducts_id=1773

  14. #12
    Senior Member
    Join Date
    Apr 2008
    Location
    London
    Posts
    1,096
    Thanks
    35
    Thanked
    83 times in 69 posts
    • Bugbait's system
      • Motherboard:
      • Gigabyte Z370 Auros Gaming 7
      • CPU:
      • Intel i8 8700K (Watercooled)
      • Memory:
      • 2 x 16GB DDR4 Corsair LPX 4000Mhz
      • Storage:
      • Samsung 960 EVO 500GB, Samsung 850 EVO 500GB, SS 1TB, WD 2TB
      • Graphics card(s):
      • Gigabyte GTX 1080 Ti Waterforce WB Xtreme Edition
      • PSU:
      • Antec HCP-850 Platinum
      • Case:
      • Corsair Obsidian 900D (Dual D5 in series: 120.7 - EX360 + EX480) Noctua F & P12 Fans
      • Operating System:
      • Windows 10 Pro x64
      • Monitor(s):
      • LG 31MU97
      • Internet:
      • VM Cable (100Meg)

    Re: Corsair 800D, Watercooled log

    Quote Originally Posted by TAKTAK View Post
    The Thermochill excels in terms of low restriction, and has overall performance in terms of robustness with fans used, in that low static pressure will still reap decent results, but as Fraz rightly says, the XSPC RX360 pulls slightly ahead while using lower static pressure, i'm not 100% sure but i think the RX is more restrictive too
    The Thermochill PA and RX360 are two of the least restrictive radiators on the market. The Thermochill is less restrictive, but only slightly .

    http://www.skinneelabs.com/triplesv2.html?page=2

  15. #13
    Not a good person scaryjim's Avatar
    Join Date
    Jan 2009
    Location
    Manchester
    Posts
    15,029
    Thanks
    1,193
    Thanked
    2,242 times in 1,844 posts
    • scaryjim's system
      • Motherboard:
      • Dell Inspiron
      • CPU:
      • Core i5 8250U
      • Memory:
      • 1x 8GB DDR4 2400
      • Storage:
      • 128GB M.2 SSD + 1TB HDD
      • Graphics card(s):
      • Radeon R5 230
      • PSU:
      • Battery/Dell brick
      • Case:
      • Dell Inspiron 5570
      • Operating System:
      • Windows 10
      • Monitor(s):
      • 15" 1080p laptop panel

    Re: Corsair 800D, Watercooled log

    Quote Originally Posted by Hicks12 View Post
    Need to find a suitable case ...
    *shrug* You could always heavily mod an unsuitable case, like I'm going to

  16. #14
    I R Toff Pandi! TAKTAK's Avatar
    Join Date
    Mar 2008
    Location
    Vergon6
    Posts
    7,410
    Thanks
    525
    Thanked
    995 times in 735 posts
    • TAKTAK's system
      • Motherboard:
      • MSI P55 GD65
      • CPU:
      • i7 860 @ 3.62GHz under an XSPC RASA
      • Memory:
      • 8GB 2133MHZ Corsair Vengeance
      • Storage:
      • 80GB Intel G2 SSD + 500GB + 640GB + 250GB WD AAKs + 2x1TB Samsung (1 Dead) + 500GB Maxtor
      • Graphics card(s):
      • EVGA SSC GTX260 216 55nm under an EK FC260 GTX
      • PSU:
      • Corsair HX620w
      • Case:
      • Corsair 800D, PA120.3 in the roof with 6 NF-P12s in Push-Pull
      • Operating System:
      • 7 x64
      • Monitor(s):
      • 24" Yuraku YV24WBH1 - SA-LTM240M2-L01 Panel & 32" LCD HDTV (1080i) Digihome tesco special :D
      • Internet:
      • 76Mb Fibre

    Re: Corsair 800D, Watercooled log

    Eeee gads, just rebuilt into the 800D, came to boot up and get boot manager missing, fiddle around to get my SSD working, BSOD everytime it gets to the windows logo fiddle some more, remove the overclock, try to reboot and nothing, keeps trying, and again until the BIOS decides it has failed and chucks up an error sayign overclock failed, then starts trouble shooting and floppy failure... Eh?

    But it now seems to have fixed itself during the trouble shooting phase so quids in

    WC stuff should be here tomorrow then i can make a start, but first piccys of the beast...

    It seems that the case gods were kind to me and it arrived without damage via DHL (cheers Dabs)


    This thing is HUUUUUUGE:



    And no... I don't have novelty sized furniture

    More pics in a bit when they've uploaded
    Post Counts and Other Rewards, Rules, Folding@Home, Fans: Push vs Pull vs Push-Pull, Corsair PSU OEMs.

    Quote Originally Posted by razer121 View Post
    Would you like me to enter you? it would be my pleasure
    TAKTAK.co.uk

  17. #15
    I R Toff Pandi! TAKTAK's Avatar
    Join Date
    Mar 2008
    Location
    Vergon6
    Posts
    7,410
    Thanks
    525
    Thanked
    995 times in 735 posts
    • TAKTAK's system
      • Motherboard:
      • MSI P55 GD65
      • CPU:
      • i7 860 @ 3.62GHz under an XSPC RASA
      • Memory:
      • 8GB 2133MHZ Corsair Vengeance
      • Storage:
      • 80GB Intel G2 SSD + 500GB + 640GB + 250GB WD AAKs + 2x1TB Samsung (1 Dead) + 500GB Maxtor
      • Graphics card(s):
      • EVGA SSC GTX260 216 55nm under an EK FC260 GTX
      • PSU:
      • Corsair HX620w
      • Case:
      • Corsair 800D, PA120.3 in the roof with 6 NF-P12s in Push-Pull
      • Operating System:
      • 7 x64
      • Monitor(s):
      • 24" Yuraku YV24WBH1 - SA-LTM240M2-L01 Panel & 32" LCD HDTV (1080i) Digihome tesco special :D
      • Internet:
      • 76Mb Fibre

    Re: Corsair 800D, Watercooled log

    It's go time (PS, Gonz, that GTX480 block is the sex ):

    Box:



    More box:



    Bag:



    Oooh:



    Back:



    Top:



    Blank side:



    Windowed side, shaped somewhat like a sail, quite fitting for Corsair really...:



    Bottom:



    Dust filter:



    Case side release:



    The abyss:



    Accessories (P4 extension, SATA power (for the hotswaps), 4 90 degree sata data, rubber gasket for 120mm fan, cable ties, assorted screws, HDD brackets for lower cage):





    The backplate access hole, is farking huge...:





    More in a sec ...
    Post Counts and Other Rewards, Rules, Folding@Home, Fans: Push vs Pull vs Push-Pull, Corsair PSU OEMs.

    Quote Originally Posted by razer121 View Post
    Would you like me to enter you? it would be my pleasure
    TAKTAK.co.uk

  18. #16
    I R Toff Pandi! TAKTAK's Avatar
    Join Date
    Mar 2008
    Location
    Vergon6
    Posts
    7,410
    Thanks
    525
    Thanked
    995 times in 735 posts
    • TAKTAK's system
      • Motherboard:
      • MSI P55 GD65
      • CPU:
      • i7 860 @ 3.62GHz under an XSPC RASA
      • Memory:
      • 8GB 2133MHZ Corsair Vengeance
      • Storage:
      • 80GB Intel G2 SSD + 500GB + 640GB + 250GB WD AAKs + 2x1TB Samsung (1 Dead) + 500GB Maxtor
      • Graphics card(s):
      • EVGA SSC GTX260 216 55nm under an EK FC260 GTX
      • PSU:
      • Corsair HX620w
      • Case:
      • Corsair 800D, PA120.3 in the roof with 6 NF-P12s in Push-Pull
      • Operating System:
      • 7 x64
      • Monitor(s):
      • 24" Yuraku YV24WBH1 - SA-LTM240M2-L01 Panel & 32" LCD HDTV (1080i) Digihome tesco special :D
      • Internet:
      • 76Mb Fibre

    Re: Corsair 800D, Watercooled log



    Still with transit tape in place:











    Lower 3.5" bays (can fit a fan to it if wanted):



    PSU area:



    Mobo hole again:



    Would have been humorous to have a cat staring through the hole, but i don't have a cat...:



    Instructions:







    And that is as much action as they got, i'm not entirely sure where they are now :/

    Naked!:

    Post Counts and Other Rewards, Rules, Folding@Home, Fans: Push vs Pull vs Push-Pull, Corsair PSU OEMs.

    Quote Originally Posted by razer121 View Post
    Would you like me to enter you? it would be my pleasure
    TAKTAK.co.uk

Page 1 of 9 1234 ... LastLast

Thread Information

Users Browsing this Thread

There are currently 1 users browsing this thread. (0 members and 1 guests)

Similar Threads

  1. Corsair Begins UK/EU RMA Processing
    By Yellowbeard in forum Cooling
    Replies: 0
    Last Post: 17-06-2008, 06:31 PM
  2. Corsair Begins UK/EU RMA Processing
    By Yellowbeard in forum Solid State Drives (SSD)
    Replies: 0
    Last Post: 17-06-2008, 06:30 PM
  3. Replies: 0
    Last Post: 06-12-2005, 10:35 PM
  4. Corsair on TCCD Supply
    By Steve in forum HEXUS News
    Replies: 0
    Last Post: 20-06-2005, 04:34 PM
  5. Corsair RAM
    By skattrd in forum Retail Therapy and Bargains
    Replies: 12
    Last Post: 13-05-2005, 03:02 PM

Posting Permissions

  • You may not post new threads
  • You may not post replies
  • You may not post attachments
  • You may not edit your posts
  •
