    Heatsink with 3 screws

    just had a heatsink screw break off into my motherboard.

    anyone successfully ran a heatsink using only 3 screws insted of 4?

  2. #2
    Banned
    Join Date
    Feb 2008
    Location
    Carlisle
    Posts
    4,121
    Thanks
    504
    Thanked
    368 times in 278 posts
    • matty-hodgson's system
      • Motherboard:
      • Abit IP35 Dark Raider
      • CPU:
      • Q6600 @ 4GHz (59'C Under a TRUE Black)
      • Memory:
      • 4GB OCZ DDR2 890MHz (5-4-4-15)
      • Storage:
      • Intel 80GB - Games. Intel 80GB - OS. 1TB Samsung - Storage.
      • Graphics card(s):
      • NVIDIA Zotac GTX 275: 728 Core, 1614 Shader, 1340 Memory
      • PSU:
      • Enermax MODU82+ 625w
      • Case:
      • Antec 300
      • Operating System:
      • Windows 7 x64
      • Monitor(s):
      • Samsung SM2343BW (2048x1152)
      • Internet:
      • Smallworld 4Mbps

    Re: Heatsink with 3 screws

    I've ran a heatsink with only 3 attached before, accidentally, and the result was about 10'C higher temps across the CPU..

    I wouldn't risk it tbh, but others might advise otherwise.

  3. #3
    Not a good person scaryjim's Avatar
    Join Date
    Jan 2009
    Location
    Manchester
    Posts
    15,110
    Thanks
    1,210
    Thanked
    2,255 times in 1,855 posts
    • scaryjim's system
      • Motherboard:
      • Dell Inspiron
      • CPU:
      • Core i5 8250U
      • Memory:
      • 1x 8GB DDR4 2400
      • Storage:
      • 128GB M.2 SSD + 1TB HDD
      • Graphics card(s):
      • Radeon R5 230
      • PSU:
      • Battery/Dell brick
      • Case:
      • Dell Inspiron 5570
      • Operating System:
      • Windows 10
      • Monitor(s):
      • 15" 1080p laptop panel

    Re: Heatsink with 3 screws

    Essentially one corner of the heatsink won't sit properly, so that part of the CPU will get hotter than usual. Probably ok for a day or two, but I personally wouldn't risk it for any longer than that - pick up either a new screw, or a new heatsink, ASAP!

  4. #4
    DDY
    DDY is offline
    Senior Member DDY's Avatar
    Join Date
    Jun 2006
    Posts
    2,740
    Thanks
    147
    Thanked
    566 times in 392 posts
    • DDY's system
      • Motherboard:
      • ASRock Z390M Pro 4
      • CPU:
      • i5 9600k
      • Memory:
      • 16GB (2x8GB) 3200MHz CL16 Corsair Vengence
      • Storage:
      • Adata SX8200 NVME 1TB
      • Graphics card(s):
      • RX 5700
      • PSU:
      • Seasonic Focus Gold 550W
      • Operating System:
      • Win 7 Pro
      • Monitor(s):
      • Dell U2715H

    Re: Heatsink with 3 screws


  5. #5
    ɯʎɔɐɹsɐʌʍ mycarsavw's Avatar
    Join Date
    Feb 2007
    Posts
    4,945
    Thanks
    1,097
    Thanked
    653 times in 482 posts
    • mycarsavw's system
      • Motherboard:
      • P8H77-M Pro
      • CPU:
      • i5 3350P
      • Memory:
      • 16Gb
      • Storage:
      • Lots
      • Graphics card(s):
      • R9 285
      • PSU:
      • HX 620w
      • Case:
      • FD Define Mini
      • Operating System:
      • W10
      • Monitor(s):
      • BenQ G2420HDBL + GL2450HT
      • Internet:
      • Sky

    Re: Heatsink with 3 screws

    I thought this was a for sale thread - sounded like a good deal too

    Do as the wolf says above but use (a big) cable tie(s) to keep the other two screw-less corners down?
    |Kata: "Read title as 'fisting'. Not sure why I clicked. Relieved, really."|
    |TAKTAK: "It was so small that mine wouldn't fit into it"|

  6. #6
    It's good to be bad pauldarkside's Avatar
    Join Date
    Oct 2006
    Location
    Cornwall
    Posts
    2,930
    Thanks
    295
    Thanked
    378 times in 259 posts
    • pauldarkside's system
      • Motherboard:
      • ASUS Maximus VI Hero
      • CPU:
      • Intel Core i7-4770K & Corsair Hydro H80i
      • Memory:
      • Corsair Vengeance 32GB (4x8GB) 1600MHz DDR3
      • Storage:
      • Corsair Force GS 128GB, Crucial M500 480GB, WD Black 4TB
      • Graphics card(s):
      • EVGA GeForce GTX 780 Ti Superclocked
      • PSU:
      • Corsair Professional HX850W
      • Case:
      • Corsair Graphite 780T (White)
      • Operating System:
      • Windows 8.1 Pro 64bit
      • Monitor(s):
      • Asus ROG Swift PG278Q
      • Internet:
      • BT Infinity @ 78Mbps

    Re: Heatsink with 3 screws

    What about using a hand drill (less vibration on the motherboard) with a small bit to remove the duff screw?
    My only concern is should I hide my true identity? A costume maybe?

    0iD: Plus weeing in it every now & again does it good
    scaryjim: 10" is just a little large to hold comfortably in one hand, which makes it a lot harder to tap, swipe and generally interact with.

  7. #7
    Senior Member
    Join Date
    Mar 2008
    Posts
    799
    Thanks
    66
    Thanked
    71 times in 70 posts
    • kmac's system
      • Motherboard:
      • Gigabyte GA-P55-US3L
      • CPU:
      • Intel Core i5 750
      • Memory:
      • 2GB Corsair DDR3
      • Storage:
      • 2 Samsung F3 500GB each
      • Graphics card(s):
      • ATI HD4770
      • PSU:
      • Enermax Modu 82+ 525W
      • Case:
      • Lain -Li PC-7FN Black
      • Operating System:
      • Windows 7 Prof 64 Bit
      • Monitor(s):
      • Dell U2412M

    Re: Heatsink with 3 screws

    Didn't realise the screws actually screw into the motherboard. Thought they just went through the holes in the MB and sandwiched the MB with nuts.

  8. #8
    Senior Member Pob255's Avatar
    Join Date
    Apr 2007
    Location
    The land of Brum
    Posts
    9,964
    Thanks
    580
    Thanked
    1,199 times in 1,102 posts
    • Pob255's system
      • Motherboard:
      • Asus M5A99X EVO
      • CPU:
      • PhenomII x4 955 & CM Hyper 212+
      • Memory:
      • 2x 4gb Corsair Vengence 1600mhz cas9
      • Storage:
      • 250gb SATA Westerndigital + 500gb samsung +1tb Samsung
      • Graphics card(s):
      • Asus GTX560ti CuII
      • PSU:
      • Be Quiet E9 680w
      • Case:
      • HAF 912+
      • Operating System:
      • W7 Pro
      • Monitor(s):
      • Dell 21" ips something

    Re: Heatsink with 3 screws

    Yes, it shouldn't screw into the motherboard, but a plastic bracket (which can be removed) or a backplate.

    If the screw was too large for the hole in the motherboard then you might of been screwing into it, although you motherboard will not of been made for that.

    You could try (very carefully) using needle nose pliers to grip the broken off screw and turning it to get it out.

    PS One thing about not connecting a socket 775 stock cooler with all 4 pins and I've seen this happen.
    We had a pc at work that kept turning it's self off, I opened it up to discover the stock heat sink laying on the bottom of the case.
    after investigation I figured out what happened, one or two of the top push pins was not in correctly, now the stock intel paste is wax based, it's designed to melt with heat and reharden when cooled, what happened was the paste melted, and flowed away from the unsecure corner, then reharden when the pc was turned off, building up in the sight gap and pushing against the cooler untill the pressure from this action caused the remaining pins to pop out and the cooler to fall off.
    I could tell this from the way the paste was now only covering half of the coolers copper plate yet was thickest in the center.
    After finding that I double checked the rest of that batch of pc's and I found one other with and incorrectly pushed in pin, the same thing was happening to that one but it hadn't got as far as detaching the other pins, it was lifting off the cpu in one corner as the paste built up and the cooler fan was really working hard to try to cool it.
